Sensor Imu Fusion Breakout Adafruit Bno055 De 9 Puntos

Descripción

Key Features
--------------------
- 9-DOF Sensor Capabilities: Get comprehensive sensor data including accelerometer, gyroscope, and magnetometer for 3D space orientation.
- Onboard Sensor Fusion: Pre-integrated algorithms deliver orientation data without the hassle of complex programming.
- High-Frequency Output: Obtain various vectors and orientation data at rates up to 100Hz for real-time applications.
- Additional Measurement Tools: Measures magnetic field, linear acceleration, gravity, and temperature for diverse projects.
- Ready-to-Use Breakout Board: Includes 3.3V regulator, logic level shifting, external crystal, and pin breakouts for easy integration.

Fact Sheet
--------------------
- Dimensions: 20mm x 27mm x 4mm
- Mounting Holes: 20mm apart, begin 4mm from the edge of the board
- I2C Addresses: 0x28 (default) or 0x29
- Weight: 3 grams
- Output Data: Absolute orientation (Euler Vector at 100Hz & Quaternion at 100Hz), Angular velocity Vector (100Hz), Acceleration Vector (100Hz), Magnetic Field Strength Vector (20Hz), Linear Acceleration Vector (100Hz), Gravity Vector (100Hz), Temperature
- Power and Connectivity: Requires soldering header to the breakout PCB, 3.3V power supply
- Extra Features: Logic level shifting for Reset and I2C pins, an external 32.768 kHz crystal

The Adafruit BNO055 Sensor Breakout board is a powerful ally for anyone delving into the world of motion tracking and orientation. With its 9-degrees-of-freedom (DOF) sensor, this compact board makes it incredibly easy for innovators, hobbyists, and engineers to obtain precise and real-time orientation and motion data. Designed for seamless integration, the breakout comes with a range of features that simplify development. Whether you are looking to enhance your robotics project, create an interactive installation or build a sophisticated navigation system, this Adafruit sensor breakout is your go-to for reliable and accurate orientation data. Plus, its added measurements of the magnetic field, gravity, and temperature open up possibilities for environmental sensing and data logging, making it a versatile tool for your electronic and IoT projects.
